Regulatory Information

Zivid 3

The Zivid 3 camera is compliant to international product compliance standards and regulations as listed below. All product compliance for this product is documented in test reports and certificates referencing type number ZVC-02. All compliance-testing referred is performed by accredited 3rd party laboratories. Please contact Zivid for access to certificates, declarations of conformity or other publicly available compliance documents.

Product Safety

• International: Standard IEC 62368-1.

• EU/EFTA (EEA): Standard EN 62368-1 and Directive 2014/35/EU (LVD)

• USA: Standard UL 62368-1

• Canada: Standard CAN/CSA-C22.2 NO. 62368-1

• Australia & New Zealand: Standard AS/NZS 3820 and National Differences AS/NZS 62368.1

Electromagnetic Compatibility (EMC)

• International: Standards CISPR 32 and CISPR 35, IEC 61000-3-2 and IEC 61000-3-3 (Note 1)

• EU/EFTA (EEA): Standards EN 55032, EN 55035, EN 61000-3-2, EN 61000-3-3 and Directive 2014/30/EU (EMC) (Note 1)

• USA: Standard FCC CFR 47 Subpart 15B (Note 2 and 3)

• Canada: Standard ICES-003 (Note 4)

• South Korea: Standards KS C 9832 and KS C 9835

• Australia & New Zealand: Standards EN 55032 (ACMA)

Photobiological and Laser Safety

• International: Standards IEC 60825-1 and IEC 62471-5 (Note 6)

• EU/EFTA (EEA): Standards EN 60825-1 and EN 62471-5

• USA: Standards 21 CFR 1040.10 & 21 CFR 1040.11 and Laser Notice No. 56 and 57 (Note 7)

Ingress protection

• EU/EFTA (EEA): Standard EN 60529 (IP65) (Note 9)

Environmental Compliance

• EU/EFTA (EEA): Directive 2011/65/EU with amd. (EU) 2015/863 (RoHS). Regulation (EC) No 1907/2006 (REACH)

• USA: TSCA PBT and TSCA PFAS

Notes

1. EMC Class B limits

   The product has been tested according to CISPR32/EN 55032 and complies with Class B limits.

2. USA - FCC CFR 47 Subpart 15B, Class B Compliance Statement

   This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

3. USA - FCC CFR 47 Subpart 15B, Class B Interference Statement

   This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

   This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

   • Reorient or relocate the receiving antenna.

   • Increase the separation between the equipment and receiver.

   • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

   • Consult the dealer or an experienced radio/TV technician for help.

4. Canada - ICES-003, EMC Class B limits

   This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

5. Signal protection

   Do not install Zivid cameras and cables next to high voltage devices that can generate high levels of electromagnetic disturbance. Do not route camera cabling through the same trunks/ conduits with AC power cables and cables emitting high levels of disturbance.

6. Photobiological Safety for image projectors

   The complete product is tested according to standard IEC 60825-1 (cl.4.4 - Laser products designed to function as conventional lamps) and found to comply with Laser Class 1. The entire product is also tested according to standard IEC 62471-5 and found to comply with Risk Group 2.

7. USA - Compliance with FDA Performance Standards

   This product complies with FDA performance standards for laser products except for conformance as a Risk Group 2 LIP as defined in IEC 62471-5: Ed. 1.0. For more information see Laser Notice 56 and 57, dated May 8, 2019.

8. Do not stare into the beam

   As with any bright light source, do not stare into the beam, RG2 IEC 62471-5.

   The image projector is an integral part of the product:



   Avoid the use of optical aids such as binoculars or telescopes inside the beam projected through the projector (lamp aperture).

9. Fan-duct

   The camera’s fan-duct is outside the IP65 classified enclosure (the fan itself is classified as minimum IP65).

General Warnings

1. Mounting

   Read the mounting instructions before installation and follow these thoroughly. Use the intended mounting accessories and hardware. Mounting the camera incorrectly could result in hazardous situations, malfunctions, or damage to the camera.

2. Controls and adjustments

   Caution - Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. Testing and approvals specified in this document have been performed using the parameters and adjustments described. Additional fault conditions and abnormal operations are evaluated throughout the compliance process. Nevertheless, use-, control- or adjustments of the camera, not anticipated at the time of approval and not specified in this document, may result in hazardous radiation exposure.

3. Ambient temperature

   Do not use the product in areas where ambient temperature exceeds the specified range given in the datasheet. This could cause overheating, result in hazardous situations, malfunctions or damage to the camera.

4. Cooling clearance

   Zivid cameras use active and passive cooling, allow some space around the device for airflow, and do not block the air opening on its front and rear sides. See the datasheets for the operating temperature range for your camera.

5. Do not open or modify

   The device contains no user-serviceable parts inside. Do not try to open or modify this product. This will:

   • Void the regulations listed above.

   • Might limit the intended use of the equipment.

   • Might cause hazardous situations.

   • Might expose you to hazardous light emission, above the levels of eye safety.

   • Might cause electrical- and fire hazards due to exposure of hazardous electrical power levels.

   • Might lead to harmful interference with other equipment or radio communication.

   • Might cause damage to the system.

6. Power supply and cables

   We strongly recommend using Zivid Power Supply and Zivid’s Cables with all Zivid cameras to ensure compliance with Safety and EMC emission and immunity standards.

Product marking (Rating label)

1. Label Artwork



2. Warnings



3. Explanation of symbols

   Symbol	Explanation
   	The product must be supplied from a DC power source.
   	After the product’s end of life, it must be handled according to any national laws and regulations for electronic waste. Do not discard the product as unsorted waste.
   	Read the user manual.

4. Location



Zivid 2+

The Zivid 2+ camera is compliant to international product compliance standards and regulations. Among these are:

Product Safety

• International: IEC 62368-1, documented in CB test report and -certificate.

• USA and Canada: UL 62368-1/CAN/CSA-C22.2 NO. 62368-1, documented in NRTL Description report and certificate.

• Europe: EN 62368-1, documented in European group differences and national differences to CB test report, European Directive 2014/35/EU (LVD).

• Australia: AS/NZS 3820, documented in Letter of Authorization.

Electromagnetic Compatibility (EMC)

• International: CISPR 32 and CISPR 35, IEC 61000-3-2 and IEC 61000-3-3.

• Europe: EN 55032 Class B, EN 55035, EN 61000-3-2 and EN 61000-3-3, European Directive 2014/30/EU (EMC).

• USA: FCC15B Class B (see note 1).

• Canada: ICES-003 (B) / NMB-003 (B) (see note 2).

• South Korea: KS C 9832 and KS C 9832.

Photobiological Safety

• International: IEC 62471-5, Classified acc. to risk group 2. Documented in CB test report and -certificate (see note 3).

Ingress protection

• EN 60529 - The product is tested for compliance according to IP65. (See note 4).

Environmental Compliance

• Europe: RoHS Directive 2011/65/EU with amd. (EU) 2015/863. REACH Regulation (EC) No 1907/2006.

Notes

1. USA - EMC Class B

   FCC Compliance Statement:

   This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

   FCC Class B Interference Statement:

   This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

   This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

   If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

   • Reorient or relocate the receiving antenna.

   • Increase the separation between the equipment and receiver.

   • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

   • Consult the dealer or an experienced radio/TV technician for help.

   Do not modify the equipment:

   Changes or modifications to the equipment not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. I.e.: Do not modify the equipment. This will:

   • Void the regulations listed above.

   • Might limit the intended use of the equipment.

   • Might cause hazardous situations.

   • Might lead to harmful interference with other equipment or radio communication.

   • Might cause damage to the system.

2. Canada - EMC Class B

   This Class B digital apparatus complies with Canadian ICES-003.

   Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

3. Photobiological Safety, Risk Group 2

   As with any bright light source, do not stare into the beam, RG2 IEC 62471-5.



4. Ingress Protection

   The camera’s fan-duct is outside the IP65 classified enclosure (the fan itself is classified as minimum IP65).

5. Mounting

   Read the mounting instructions before installation and follow these thoroughly. Use the intended mounting accessories and hardware. Mounting the camera incorrectly could result in hazardous situations, malfunctions, or damage to the camera.

6. Ambient temperature

   Do not use the product in areas where ambient temperature exceeds the specified range given in the datasheet. This could cause overheating, result in hazardous situations, malfunctions or damage to the camera.

7. Explanation of symbols marked on the product

   Symbol	Explanation
   	The product must be supplied from a DC power source.
   	After the product’s end of life, it must be handled according to any national laws and regulations for electronic waste. Do not discard the product as unsorted waste.
   	Read the user manual.

8. Compliance documentation

   Please contact Zivid for access to declarations of conformity or other publicly available compliance documents.

Zivid 2

The Zivid 2 camera is compliant to international product compliance standards and regulations. Among these are:

Product Safety

• International: IEC 62368-1, documented in CB test report and -certificate.

• USA and Canada: National Differences to CB test report according to UL 62368-1/CAN/CSA-C22.2 NO. 62368-1.

• Europe: EN 62368-1, documented in European group differences and national differences to CB test report, European Directive 2014/35/EU (LVD).

• Australia: National Differences to CB test report according to AS/NZS 62368.1.

Electromagnetic Compatibility (EMC)

• International: CISPR 32 and CISPR 35, IEC 61000-3-2 and IEC 61000-3-3.

• Europe: EN 55032 Class B, EN 55035, EN 61000-3-2 and EN 61000-3-3, European Directive 2014/30/EU (EMC).

• USA: FCC15B Class B (see note 1).

• Canada: ICES-003 (B) / NMB-003 (B) (see note 2).

• South Korea: KS C 9832 and KS C 9832.

Photobiological Safety

• International: IEC 62471-5, Classified acc. to risk group 2. Documented in CB test report and -certificate (see note 3).

Ingress protection

• EN 60529 - The product is tested for compliance according to IP65. (See note 4).

Environmental Compliance

• Europe: RoHS Directive 2011/65/EU with amd. (EU) 2015/863. REACH Regulation (EC) No 1907/2006.

Notes

1. USA - EMC Class B

   FCC Compliance Statement:

   This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

   FCC Class B Interference Statement:

   This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

   This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

   If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

   • Reorient or relocate the receiving antenna.

   • Increase the separation between the equipment and receiver.

   • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

   • Consult the dealer or an experienced radio/TV technician for help.

   Do not modify the equipment:

   Changes or modifications to the equipment not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. I.e.: Do not modify the equipment. This will:

   • Void the regulations listed above.

   • Might limit the intended use of the equipment.

   • Might cause hazardous situations.

   • Might lead to harmful interference with other equipment or radio communication.

   • Might cause damage to the system.

2. Canada - EMC Class B

   This Class B digital apparatus complies with Canadian ICES-003.

   Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

3. Photobiological Safety, Risk Group 2

   As with any bright light source, do not stare into the beam, RG2 IEC 62471-5.



4. Ingress Protection

   The camera’s fan-duct is outside the IP65 classified enclosure (the fan itself is classified as minimum IP65).

5. Mounting

   Read the mounting instructions before installation and follow these thoroughly. Use the intended mounting accessories and hardware. Mounting the camera incorrectly could result in hazardous situations, malfunctions, or damage to the camera.

6. Ambient temperature

   Do not use the product in areas where ambient temperature exceeds the specified range given in the datasheet. This could cause overheating, result in hazardous situations, malfunctions or damage to the camera.

7. Explanation of symbols marked on the product

   Symbol	Explanation
   	The product must be supplied from a DC power source.
   	After the product’s end of life, it must be handled according to any national laws and regulations for electronic waste. Do not discard the product as unsorted waste.
   	Read the user manual.

8. Compliance documentation

   Please contact Zivid for access to declarations of conformity or other publicly available compliance documents.

Version History

SDK	Changes
2.17.0	Added support for Zivid 3 XL250.
2.14.0	Added support for Zivid 2+ MR130, LR110, and MR60.
2.12.0	Zivid One+ has reached its End-of-Life and is no longer supported.
